SPECIFICATIONS

Name: 5G CPE LTE WIFI Hotspot Wireless 5G CPE WIFI 6 Router
SKU: 5g-cpe-lte-wifi-hotspot-wireless-5g-cpe-wifi-6-router
Price: 103.00 USD
Availability: InStock

2.4g wi-fi transmission rate: 600Mbps

5G Wi-Fi Transmission Rate: 1000Mbps

Antennas: built-in antennas

Brand: BAILING

CPU: MT7981B AX3000

Country Version: EU Version,US Version

Encryption Type: WPA2-PSK,WPA2,WPA-PSK

Interface: 2LAN+1WAN

Module: RG501Q-EU/RM502Q-GL/RM500Q-GL/FM150-GL/FM350-GL

Name: 5G CPE WIFI 6 Router

Power supply: DC 12V 2A

SIM CARD Slot: 1 Nano-SIM

Support: Web/Band Lock/OpenWRT/Sysupgrade/Change imei/AT command/Mesh/Firewall

Supports WDS: No

Supports WPS: No

WAN Ports: 1

WIFI: WiFi 2.4G/5G

Warranty: 1 Year

WiFi Transmission Standard: 802.11b,802.11g,802.11n,802.11ac,WiFi 802.11 ax

Wireless Speed: 3000Mbps

application: Network Security

function: WIFI,FireWall,QoS,VPN

lan ports: 2

max. lan data rate: 2.5Gbps

place of origin: Guangdong, China

products status: New

standards and protocols: Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n,Wi-Fi 802.11ac

type: Wireless

wifi supported frequency: 2.4G & 5G

wired transfer rate: 10/100/1000Mbps

with modem function: No

3000Mbps Wifi6 Cpe Router 5g Lte Wifi Router with Sim Slot

Product Description

5G CPE Router with 5G Module & Sim Slot

802.11ax Openwrt 21 dual band gigabit wireless wifi dual sim card wifi6 4g 5g sim modem router

This model is a 5G+WIFI6 home CPE router that accesses the Internet through 5G mobile communication dial-up or 1000Mbps WAN port, and then shares the Internet network through wireless WiFi 6 and 1000Mbps wired LAN. In addition, this product is compatible with dual SIM cards and uses a PHY network port chip to directly communicate with the 5G module. This improves the communication rate between the 5G module and the routing SOC, and enables end users to obtain a faster and more stable 5G network.

Different 5G cellular modules fit different regions and market positioning needs.Please let me know your country and needs. We would like to choose 5G module and quote the price for you
5G Module	RG501Q-EU	SDX55
	RM520N-GL	SDX62
	RM551E-GL	SDX75
	FM190W-GL	SDX75
	RG500U-EA	V710
	RG200U-CN	V510
	FM350-GL	MT T700
	FM150	SDX55
	FM160	SDX62
5G NR	RG501Q-EU NSA n1/3/5/7/8/20/28/38/40/41/77/78 SA n1/3/5/7/8/20/28/38/40/41/77/78 LTE-FDD B1/3/5/7/8/20/28/32 LTE TDD B38/40/41/42/43 WCDMA B1/5/8
	RM520N-GL NSA n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79 SA n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79 LTE-FDD B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 13/ 14/ 17/ 18/ 19/ 20/ 25/ 26/ 28/ 29/ 30/ 32/ 66/ 71 LTE-TDD B34/ 38/ 39/ 40/ 41/ 42/ 43/ 48 LAA: B46 WCDMA B1/ 2/ 4/ 5/ 8/ 19
	RM551E-GL NSA n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29(Rx)/30/38/40/41/48/53/66/70/71/75/76/77/78/79 SA n1/2/3/5/7/8/12/13/14/18/20 25/26/28/29(Rx)/30/38/40/41/53/48/66/70/71/75/76/77/78/79 LTE-FDD B1/2/3/4/5/7 8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71 LTE TDD B34/38/39/40/41/42/43/48 LAA: B46 WCDMA B1/2/4/5/8/19
	RG500U-EA NSA n1/3/7/38/40/41/77/78 SA n1/3/5/7/8/20/28/38/40/41/66/71/77/78 LTE-FDD B1/2/3/4/5/7/8/20/28/66 LTE TDD B38/40/41 WCDMA B1/2/5/8
	FM350-GL 5G SA/NSA Sub-6: n1/2/3/5/7/8/20/25/28a/28b/30/38/40/41/48/66/71/77/78/79/80/81/82/83/84 LTE FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28a/28b/29/30/32/ 66/71 LTE TDD: B34/38/39/40/41/42/43/48 WCDMA: B1/2/4/5/8
Data Rate	5G SA Transmission Speed:2.1Gbps/900Mbps (up to ISPs) 5G NSA Transmission Speed:2.5Gbps/650Mbps (up to ISPs) LTE : Down 1.0 Gbps;UP 200 Mbps

Item	5G CPE WIFI 6 Router
Wireless Rate	AX3000Mbps
CPU	MT7981BA+MT7976CN+MT7531AE(Dual-core A53 1.3GHz)
WiFi 6	2.4G / 5G ,2.4GHz 2TR :600Mbps , 5GHz 2T2R 2400Mbps
Ethernet	1* WAN/LAN 1Gbps (Support OEM 2.5Gbps) 2* LAN 1Gbps
Sim Slot	1* Nano SIM card slots
Storage	512MB DDR3 + 128MB SPI NAND FLASH
Wired Transfer Rate	10/100/1000Mbps
WiFi Standard	IEEE 802.11b,g,a,n,ac,ax,IEEE 802.3,u,x
Working mode	Router / Bridge
System	Openwrt/OS
Wireless security	Wireless MAC address filtering 64/128 bit WEP encryption WPA-PSK,WPA2-PSK,WPA3-SAE,WPA/WPA2-PSK ,WPA2-PSK/WPA3-SAEWPS(PBC)
Other features	Wireless host status display Wireless site scanning Seamless roaming between nodes Seamless roaming between bands
WiFi settings	WiFi basic settings (dual-band integration, switch, wireless mode, SSID, PWD, encryption algorithm, channel, bandwidth, poweradjustment). Advanced settings (wireless client isolation, 802.11h, WMM multimedia acceleration). Multiple SSIDs (SSIDs, encryption methods, PWDs, and encryption algorithms)
Button	Mesh (press 1 second).Reset (press and hold for 5 seconds).
LED Indicator	5G, 4G, WIFI signal indicator, power indicator
Power supply	DC 12V/2A
Network settings	Data Switch, Roaming Switch, Mode Selection, Default APN Information, and APN Manual Configuration FAILOVER switches: PPPOE, DHCP, and static4G/5G band locking
WiFi settings	WiFi name and password, wifi timing, channel bandwidth setting, power regulation, bridging function, OFDMA, Mesh
SMS feature	SMS sending and receiving, SMS center settings, USSD
Guest network	Configure the SSID, rate limit, and startup time limit of the guest network
Parental controls	Online device display, online time, restricted Internet time period, URL filtering configuration
Advanced settings	Working Mode, SIM PIN, Mobile Data Switch, Bandwidth Control, Sleep Mode, LED Control, Filter MAC Address, Firewall, Static Routing, DDNS, Virtual Server, DMZ Host, UPnP, TR069 Settings, VPN(L2TP/PPTP/Wireguard/GRE/IPsec/OpenVpn),IMEI Modify,Zerotier,Smart QoS,Firewall, Domain ACL,UPnP,Remote web
System settings	System Status, Time Setting, Password Management, Configuration Management, Firmware Upgrade, Scheduled Restart, System Log, LAN Setting, DHCP Binding, Reboot & Reset, Remote Management
Use environment	Operating temperature: -20°C to 50°C Storage temperature: -40°C to 70°C Operating humidity: 10% to 90% RH non-condensing Storage humidity: 5% to 95% RH non-condensing
Application	Home/Office/Shipping mall/Enterprise
