This is a customized product, and the price shown is not the final price.Additional costs will apply depending on whether it meets Euro 5 or EPA engine requirements (for European and American countries) and whether other configurations are needed,such as cab/boom swing, etc. We offer multiple delivery methods, including DDP, EXW, FOB, CFR, and CIF. Shipping costs will be calculated separately based on the delivery method.
We can customize colors, configurations, models, appearance, logos, engine types, and powertrains. Most importantly, you need to communicate with our customer service to confirm product parameters. Specific prices vary depending on country/region and customs requirements;please contact customer service for consultation.Orders without customer service confirmation will not be shipped.
☆☆ Follow our store and become a fan to enjoy more gifts. ☆☆
3.Talk with our sales colleague, you will get exclusive one-to-one serviceand outlet sale price!
2.We ship you by sea !!!
1.This product is a customized product. Please contact customer service to select engines and accessories, inform us of the receiving port, or contact us for more product details and pricing
✨Welcome to the professional manufacturer of forklift in China✨
Diesel Forklift
FD15
FD20
FD25
FD30
FD35
FD40
FD50
Load capacity（kg)
1500
2000
2500
3000
3500
4000
5000
Load center（mm)
500
500
500
500
500
500
500
Lift height（mm)
3000
3000
3000
3000
3000
3000
3000
Full free lift height（mm)
100
100
100
100
100
0
0
Mast tilting angle（Deg)
6/12
6/12
6/12
6/12
6/12
6/12
6/12
Min.turning radius（mm)
1955
2220
2240
2400
2550
2800
3050
Groud clearance（mm)
110
120
120
135
135
135
140
Overhead guard height（mm)
2040
2140
2140
2165
2165
2230
2290
Front overhang（mm)
425
448
485
495
495
500
570
Max travel speed（km/h)
13.5
19
19
19
19
18.5
25
Max lift speed（mm/s)
590
550
550
480
480
420
430
Max.traction power（KN)
12.3
12.3
12.3
13.5
13.5
20
23
Max. gradeability（%)
20
20
20
20
20
20
18
Total length with fork（mm)
3175
3523
3610
3820
4065
4105
4520
Total length without fork（mm)
2255
2453
2540
2750
2995
3035
3300
Total width（mm)
1070
1160
1160
1225
1225
1400
1480
Mast extended height（mm)
4030
4220
4220
4265
4265
4270
4300
Mast lowered height（mm)
1995
2060
2060
2060
2060
2190
2190
Please note that the prices displayed are prepayment, please contact customer service for more discounts.
Features:
1. The core components such as gearbox and drive axle are jointly manufactured, and the key components are imported, with low failure rate and reliable quality
2. Equipped with cast steering axle, compact structure, small load deformation, dustproof and waterproof, improving service life and reliability
3. Adopting a wide field of view gantry, with a wide field of view; The section of the gantry channel steel is enlarged, and the overall structure is sturdy and reliable!
4. It adopts a large opening angle integrated machine, with an internal frame reinforcement plate structure, high strength, quality, and reliability!
5. Adopting a new type of mechanical locking mechanism, the mechanical opening and closing are more flexible and reliable in locking
6. The iron shell large air filter is used, with high strength and aging resistance. Can better adapt to harsh working environments
7. The lifting system is equipped with explosion-proof safety valves to ensure safety during the lifting process of heavy objects
8. The boarding pedal adopts a fully anti slip pedal to ensure the safety of forklift drivers getting on and off the vehicle
9. The connection between the steering bridge and the frame is supported by damping rubber pads, reducing the vibration of the entire vehicle and improving the comfort of the operator
10. The large opening angle of the machine and the external maintenance components such as the oil filter make maintenance and repair more convenient
Please note: All of our diesel forklift are custom made, please contact our sales to confirm details before/after placing an order. You will be treated friendly and sincerely, and you will find it will be very helpful.
